Scalarworks Leap scope mount

LEAP/SCOPE

Ultra high-performance scope mount.

Designed for shooters who want the lightest, most rigid, easiest to use, and least obtrusive quick-detach scope mount possible.


LEVEL HEADED

The Leap includes our proprietary leveling screw to help you conveniently square your scope with your mount.



Scalarworks Leap scope mount lightest weight

LIGHT MADE RIGHT

Engineered to be the lightest QD scope mount, without compromising an ounce of strength.

Scalarworks® SW0700 (5.48oz)
57%
LaRue® LT104 (7.09oz)
74%
ADM® AD-Recon (8.05oz)
84%
Spuhr® QDP-3016 (9.52oz)
99%
KDG® SID5-140 (9.56oz)
100%

All Trademarks are the property of their respective owners and are used in accordance with FTC Comparative Advertising guidelines. All mounts weighed under the same conditions with all hardware necessary to attach a 30mm scope.

Scalarworks LEAP scope mount clamp

state of the smart

The LEAP/Scope incorporates two of the most efficient structures known to man.

A tubular boom and an I-beam bridge, each with over-sized cross-sections, maximize rigidity and impact resistance while minimizing weight.


Scalarworks Leap scope mount FEA

Scalarworks Leap scope mount 7075-T6
Scalarworks Leap scope mount 7075-T6 vs 6061-T6

Every Leap Mount is CNC milled from 7075-T6 billet, which has vastly superior mechanical properties to 6061-T6, and is used where ultimate strength and durability outweigh cost considerations.

The One Ring

The Scalarworks® Ring was designed from the ground up to be stiffer, lighter, and easier to use than traditional rings.

Scalarworks Ring Cross Bolts

A high-strength, precision fitted hinge ensures even pressure around your optic, without requiring the tedious and imprecise setup that traditional rings do.

Scalarworks Ring Cross Bolts

Twin oversize CNC machined shoulder screws provide even tension and act as structural elements, making the entire ring assembly phenomenally rigid.

Scalarworks Ring Cross Bolts

Each side of the Scalarworks® Ring is carefully lightened with a curvature continuous scallop that produces a very high strength-to-weight ratio.

Scalarworks Ring Cross Bolts

The Scalarworks® Ring is wider than competing designs, providing more surface area to safely and securely hold your optic.

Scalarworks Leap scope mount Low Profile

Smooth is fast

Narrower than most bolt-on mounts: the Leap has no protruding levers or knobs to rap your knuckles, or get caught on clothing, gear, and surroundings.

Scalarworks Leap scope mount Quantum Quick-Detach system

Quantum

Quick-Detach Mechanism

The Scalarworks® Quantum Quick-Detach mechanism is completely recoil proof, while requiring only enough torque to firmly clamp onto a Picatinny rail. By decoupling torque from vibration resistance, the Quantum QD mechanism is intuitive, fast, and self adjusting, all without needing an imprecise knob or obtrusive lever to keep it from shaking loose. The Quantum QD's recessed head is carefully designed to deflect external impacts, while letting you take the mount off in under 3 seconds, with or without gloves.

LEAP/Scope

$399.00

ETA: 34MM (11/30), 30MM (12/30)
